CRYSTAL 140’
CRYSTAL 140’
Sguardia
PURA LUCE
PURE LIGHT
DELFINO 93’
TRADITION 105’
CLASSIC 121’
CRYSTAL 140’
VISION 145’
CLASSIC SUPREME 132’
UNDER CONSTRUCTION
Crystal 140’ è un modello unico nel suo genere che Benetti ha posto al centro della gamma Class, innovando il concetto
di navetta capace di vivere il mare con grandi spazi sopra e sotto coperta, con la conquista della luce e di nuove funzioni.
Le grandi vetrate a tutta altezza e l’ampiezza delle aree esterne evidenziano i suoi concetti ispiratori: il rapporto con il
mare e la vita all’aperto. Crystal è proposto anche nella versione più classica con il fumaiolo, antica suggestione e simbolo
delle navigazioni.
Crystal 140’ is a one of a kind model that Benetti has placed smack in the middle of the Class range. It builds on the idea of
an open water navetta with grand spaces above and below deck: a feat in day lighting and new features. The large, full-height
windows and generous exterior spaces point to the inspirational concepts: the relationship with the sea and living outdoors.
Crystal is also offered in the classic version with a smoke stack, a time-honoured boating symbol.
5
I PIù INNOVATIVI SISTEMI DI COMUNICAZIONE
E DI INTEGRAZIONE
THE MOST INNOVATIVE COMMUNICATIONS
AND INTEGRATION SYSTEMS
Benetti’s Exclusive Sea Technology
INTEGRAZIONE DEI SISTEMI DI PLANCIA
BEST è l’esclusiva piattaforma tecnologica creata da Benetti che integra tutti i sistemi elettronici
e impianti di bordo. In BEST i sottosistemi, sebbene diversi per funzionalità e tecnologie, sono
in grado di comunicare tra loro con un linguaggio comune: la televisione realmente “parla” con
le luci così come le telecamere “parlano” con i telefoni. Tutto ciò è reso possibile in quanto
ogni funzione ha un’interfaccia aperta che permette la comunicazione con il resto del sistema.
BEST, infatti, è costituito da un’infrastruttura di rete unica e da un middleware che mette in
relazione tra loro i dispositivi e le diverse componenti attraverso lo scambio di segnali ed
eventi.
Il Sistema di Plancia Integrata messo a punto da Benetti è un’innovazione tecnologica capace
di integrare e interfacciare i numerosi strumenti di navigazione attraverso un unico software
completo di hardware.
La sfida di Benetti è stata quella di progettare un sistema capace di integrare in modo
funzionale tutti gli apparati di navigazione, telecomunicazione, sicurezza e trasmissione dati
per assicurare un’estrema facilità di utilizzo e una maggiore velocità di reazione, con un
conseguente aumento della sicurezza. Il progetto, innovativo anche per la struttura modulare,
è in continua evoluzione per permettere l’integrazione della strumentazione di navigazione e
di comunicazione appartenente a più brand leader nel settore.
Benetti’s Exclusive Sea Technology
BEST is the new exclusive technologic platform created by Benetti that integrates all the onboard electrical systems.
In BEST all subsystems, although different for functionality and technology can communicate
with each other using a common language: television really “talks” to lights as well as cameras
“talk” to phones. This is possible because every function has an open interface that enables
communication with the rest of the system.
BEST is made up of a single network infrastructure and middleware software that correlate all
devices and different components through the exchange of signals and events.
Integrated Bridge System
Le immagini sono alcuni esempi di installazione a bordo. - These pictures are just examples of installation on board.
The Integrated Bridge Systems designed by Benetti represents a technological innovation
capable of integrating and interfacing all navigation instruments thanks to a single software
complete with hardware.
The Benetti challenge was to design a system which could optimise functional integration of
all navigation telecommunications, safety and data transmission instrumentation in order to
guarantee extreme ease of use and fast response time, resluting in a considerable increase in
sea safety levels. The project, with its innovative modular structure design, is constantly under
development in order to allow for the integration of navigation and communication system
from the world leading industry brands.
7
CRYSTAL 140’
9
CRYSTAL 140’
11
CRYSTAL 140’
BY001 - 2011
CRYSTAL 140’ - BY001
13
CRYSTAL 140’ - BY001
MAIN DECK
15
SUN DECK
CRYSTAL 140’ - BY001
UPPER DECK
17
SUN DECK
CRYSTAL 140’ - BY001
SUN DECK
19
MAIN DECK DINING AREA
CRYSTAL 140’ - BY001
MAIN DECK LIVING
21
UPPER DECK DINING AREA
CRYSTAL 140’ - BY001
UPPER DECK LIVING
23
MAIN DECK OWNER’S BATHROOM
CRYSTAL 140’ - BY001
MAIN DECK OWNER’S CABIN
25
CRYSTAL 140’ - BY001
LOWER DECK VIP BATHROOM
LOWER DECK VIP CABIN
27
LOWER DECK
CRYSTAL 140’ - BY001
LOWER DECK TWINS CABIN
29
CRYSTAL 140’ - BY001
LOWER DECK TWINS CABIN
Lower deck guest bathroom
31
CRYSTAL 140’ - BY001
WHEELHOUSE
33
DETTAGLI DI FUNZIONALITà
E DI ESTETICA
BOTH FUNCTIONAL
AND ESTHETIC DETAILS
CRYSTAL 140’
35
SPECIFICHE TECNICHE
TECNICHAL SPECIFICATIONS
DESCRIPTION
The vessel dealt with in this specification is a full displacement motor yacht, with bulbous bow,
twin screw propellers and twin diesel engines.
Model Crystal 140’
Builder Azimut-Benetti Spa - Benetti Shipyard, Italy
Naval Architect Azimut-Benetti Spa - Benetti Shipyard, Italy
Exterior Designer Righini Design
Interior Designer for Owner and Guest spaces Zuretti Interiors Designers
Interior Designer for Crew spaces Azimut-Benetti Spa - Benetti Shipyard, Italy
DIMENSIONS AND MAIN CHARACTERISTICS OF THE YACHT
Length overall 41.93 m - 137‘ 7’’
Beam overall 9.05 m - 29’ 8”
Draft at half load 2.14 m - 7’
Draft at full load 2.28 m - 7’ 6”
Half Load Displacement 343 tons
Full Load Displacement 378 tons
Fuel tank capacity 58,000 l - 15322 US gals
Fresh water capacity 8,000 l - 2113 US gals
Accommodation for Owner & Guests 12 persons in 6 cabins
Accommodation for Crew 7 persons in 4 cabins
PERFORMANCE AND MAIN MACHINERY
Main engines 2 x CAT C32 ACERT 1081 kW (1450 bhp) @ 2300rpm.
Gear box 2 x ZF 3356
Generators 2 x Kohler 125 kW, 380 Vac, 3 ph, 50 Hz
Propellers 2 x five fixed blades made in nickel-aluminium-bronze
Water maker Two reverse osmosis water makers (14000 l/day at 25°C sea water
temperature)
Bow thruster Eletric motor of 75 kW
CRYSTAL 140’
Stabilisers Hydraulic system for Navigation Stab and Zero Speed at anchor
Max speed at half load displacement 15.0 Knots
Cruising speed at 85% of maximum power at half load 14.0 Knots
Range at 11 Knots one generator working at 75% of maximum power 4.000 Nautical Miles
CLASSIFICATION AND CERTIFICATES
The Yacht will be built in accordance with “A.B.S. (American Bureau of Shipping) Guide for
Building and Classing Motor Pleasure Yachts” as published in February 2000 + Convention on
the International Regulations for Preventing Collusions at sea, 1972.
Class notation is @ A1, Maltese Cross A1 Yachting Service - AMS, by the American Bureau
of Shipping according to the Guide mentioned
Flag Authority Requirements, additional to Class Notation and to the Specification,
will be evaluated case by case and quoted accordingly if feasible;
As option the yacht can be built in compliance with the Large commercial yacht code (LY2)
HULL AND SUPERSTRUCTURE CONSTRUCTION
Hull and deck are entirely built in FRP (Fiberglass Reinforced Plastic) with combination of
foam core sandwich and single skin fiberglass construction.
Superstructure is built in Fiberglass Reinforced Plastic with a cored sandwich structure.
The connection between the superstructure and the main deck will be obtained by means
of stainless steel bolts and flanges and an adequate number of FRP layers according to the
Classification Society requirements.
AIR CONDITIONING SYSTEM
The system is based on the following criteria:
Summer
Outside air 35 °C - 95 F - R.H. 90 %
Inside air 22 °C - 72 F - R.H. 55 %
Sea water temperature 32 °C - 90 F
Winter
Outside air 0 °C - 32 F - R.H. 90%
Inside air 22 °C - 72 F - R.H. 50%
OUTFITTING GENERAL CHARACTERISTICS
Windlasses 2 x Electric windlasses Voltage is 380 VAC, 3 ph and power 5,500 W.
Capstans Two electric foot operated capstans
37
Anchors 2 x SHHP (super high holding power)
Chains 2 x per requirements
Gangway Telescopic 3 stages, length 5m with a walking width of 520 mm
Transom door 1 x hydraulic door opening downwards
Tender and water toys storage 1 x 6,2 m x 2,61 x 1,13 tender - 2 x 3,07 m x 1,22 x 1,16 jet-ski
ELECTRICAL SYSTEM
The electrical equipment, wiring, fixtures, etc. and its installation shall be in accordance with
the Classification Society rules.
The electrical system installed shall be to the requirements of the Classification Society and it
will generally consist of a 380VAC, 3 ph, 50 Hz system, a 220VAC, 1 ph, 50 Hz system and a
24 VDC system.
NAVIGATION AND COMMUNICATION SYSTEM
Navigation and Communication System
- Intercom system
- Radar
- SSB system
- Speed-log system
- Echosounder
- Magnetic compass
- Wind system with no moving parts and with GPS, air temperature and pressure sensors
- VHF class D
- Remote control unit for VHF
- Gyrocompass
- Rudder angle indicator
- Meteo fax
- Autopilot
- GSM phones
- GPS systems
- Telephone system integrated in B.E.S.T system
- Chart plotter system
- SAT system
ENTERTAINMENT SYSTEM
Crew Mess
- Audio Video client
CRYSTAL 140’
- CD / DVD player
- Speakers
- TV LCD 23”
- IP telephone
- Internet connection
- Satellite TV / radio signal
Beach area
- Amplification system
- Audio client
- Speakers
- Wi Fi network coverage
Twin Guest Cabins
- Client B.E.S.T. with DVD player
- Speakers
- TV LCD 26”
- IP telephone
- Internet connection
- Satellite TV / radio signal
- Wi Fi network coverage
VIP Cabins
- Client B.E.S.T. with DVD player
- Speakers
- TV LCD 26”
- IP telephone
- Internet connection
- Satellite TV / radio signal
- Wi Fi network coverage
Crew Cabins
- Audio client
- Speakers
- IP telephone
- Wall mount touch screen 6.4”
- Speakers
- TV LCD 42”
- Remote control
- IP telephone
- Internet connections
- Ipod docking station
- Satellite TV / radio signal
- Wi Fi network coverage
Owner’s Study
- Speakers
- Audio client
- Audio stereo amplification system
- IP telephone
- Ipod docking station
- Wi Fi network coverage
Galley
- Audio client
- Speakers 6.5”
- IP telephone
- Internet connection
Main Saloon
- Client B.E.S.T. with DVD player
- Sintoamplifier
- Wall mount touch screen 6.4” for A/V and domotic controls
- Speakers
- TV LCD 50”
- IP telephone
- Internet connections
- Ipod docking station
- Satellite TV / radio
- Wi Fi network coverage
Main saloon bar
- Speakers
- Wi Fi network coverage
External Main Deck
- Speakers
- Wi Fi network coverage
Wheelhouse
- Audio client
- Speakers
- IP telephone
- Internet connection
Captain’s Cabin
- Audio Video client
- CD / DVD player
- Sintoamplifier
- Speakers
- TV LCD 23”
- IP telephone
- Internet connection
- Satellite TV / radio signal
- Wi Fi network coverage
Upper Saloon
- Client B.E.S.T. with DVD player
- Wall mount touch screen 6,4” for A/V and domotic controls
- Speakers
- TV LCD 42”
- IP telephone
- Internet connections
- Ipod docking station
- Satellite TV / radio signal
- Wi Fi network coverage
Owner’s Suite
- Client B.E.S.T. with DVD player
39
Upper Deck Dining
- Speakers
- Wi Fi network coverage
External Upper Deck Aft
- Speakers
- Wi Fi network coverage
External Upper Deck Fwd
- Speakers
- Amplifier
- Audio socket
Sun Deck
- Audio client
- Speakers
- Wi Fi network coverage
Lobby and Stairs
- Speakers
DOMESTIC APPLIANCES
Main Deck, Galley and Pantry
- cooking top 90 cm
- Grill top
- Exhaust hood
- Oven 90 cm
- Oven 60 cm
- Microwave
- Dishwasher
- Garbage macerator for the sink
- Freezer
- Fridge
- Trash compactor
- Wine cellar undertop type
- Fridge drawer
- Coffee system
CRYSTAL 140’
Crew mess
- Microwave
- Dishwasher 45 cm
- Fridge/freezer
Main saloon bar
- ice maker
- frigobar
Owner’s study
- frigobar
Guest’s lobby
- frigobar
Sky lounge bar/pantry
- Ice maker
- Frigobar
- Microwave
- Dishwasher
Sun deck area
- 2 Barbecue
- Ice maker
- Frigobar
Laundry
- 2 Washers
- 2 Dryers
For selections by the Owner of the Interior Designer different or in addition to what specified
or not named in the Benetti Excellence Range, recommended Retail Prices will be compared
with the total allowances.
Walls
- Crew interior: lining will be covered with oak wood veneer;
- Guest interior: will be selected according to the interior designer;
Floor
- Crew interior: floors will be fitted according to the “Floor Plan” in the full spec.;
- Carpet will have underlay;
- Crew interior: will be fitted according to the “Floor Plan”
- Guest interior: will be fitted according to the “Floor Plan”
- Carpet will have underlay and will be stretched;
- Marble will be selected in the “Excellence” range of Benetti std selection;
Ceiling
- Crew interior: Ceiling panels will be lined with synthetic leather
- Guest interior: will be selected according to the interior designer
Door
- Doors which are not fire doors will be veneered with solid mouldings and made of double
plywood sandwich
Loose furniture
- Crew Interior: Will be supplied and installed by the Builder in accordance with the “Loose
furniture plans”
- Guest interior: will be selected according to the interior designer
Beach area
- Ice maker
- Frigobar
INTERIORS
In general materials and equipment will be purchased according to the properly style and the
Benetti Excellence Range.
41
PIANI GENERALI STANDARD
STANDARD GENERAL ARRANGEMENT
SUN DECK
MAIN DECK
UPPER DECK
LOWER DECK
I lay-out proposti rappresentano alcune delle configurazioni possibili e non necessariamente corrispondono alla versione standard.
The lay-outs shown are some of the possible options and do not necessarily correspond to the standard version.
CRYSTAL 140’
43
UNA STORIA INCESSANTE
D’INNOVAZIONE E DI STILE
AN UNENDING HISTORY
OF INNOVATION AND STYLE
Benetti è uno dei più antichi costruttori mondiali di megayacht. Fondato a Viareggio da Lorenzo Benetti nel 1873, il cantiere ha iniziato la sua attività costruendo imbarcazioni
a vela di legno destinate ad un uso commerciale per traffici locali ed internazionali, guadagnandosi rapidamente la fama di leader mondiale del settore.
Nel 1985, Azimut ha scritto una nuova pagina nella storia di Benetti. Con l’acquisto del cantiere toscano ha dato inizio ad una nuova era di management e d’investimenti di
capitali che hanno avuto come risultato Benetti così come è oggi: un cantiere moderno e tecnologicamente avanzato, pronto a recepire le sfide del futuro e in grado di offrire
ai suoi armatori gli yacht più raffinati ed esclusivi al mondo. Da allora Benetti si è sviluppato più di qualunque altro concorrente del segmento realizzando oltre 130 yacht e
specializzandosi nella produzione delle linee semi-custom, dai 93 ai 145 piedi, e nei mega yacht in acciaio ed alluminio, completamente custom oltre i 45 metri.
Nel 2003 il Gruppo Azimut-Benetti S.p.A. rileva i Cantieri Navali Fratelli Orlando di Livorno e avvia un importante piano industriale per la creazione di un polo specializzato
nella nautica da diporto, con la contestuale riconversione di un’area urbana ed un porto turistico.
Dal 2004 Benetti è riconosciuto a livello internazionale quale primo cantiere al mondo in termini di produzione di mega yacht.
Benetti is one of the world’s oldest builders of megayachts. Founded in Viareggio in 1873 by Lorenzo Benetti, the shipyard started out building wooden, masted barks for
local and international commercial purposes, quickly earning its reputation as an industry leader worldwide.
In 1985, Azimut opened a new chapter in Benetti history. The purchase of the Tuscan boatyard signalled a new era of management and capital investment that has made
Benetti what it is today: a modern, cutting-edge shipyard ready to meet the challenges of the future, able to offer its owners the world’s most exclusive and refined yachts.
Since then, Benetti’s growth has outpaced that of any other competitor in the sector; it makes over 130 yachts and specialises in the production of semi-custom ranges from
93 to 145 feet as well as completely custom steel and aluminium megayachts of over 45 metres.
In 2003, the Azimut-Benetti Group S.p.A. took over the Cantieri Navali Fratelli Orlando in Livorno, launching a major industrial plan to create a facility specialised in pleasure
boating alongside the revitalisation of an urban area and tourist port.
Since 2004 Benetti has been worldwide considered as the leader in mega yacht production.
CRYSTAL 140’
45
Tasca
Questa Brochure non costituisce in qualsiasi modo offerta con valenza contrattuale per la vendita di imbarcazioni del cantiere a persone o società. Tutte le informazioni contenute nella Brochure, ivi
compreso senza limitazione dati tecnici, prestazionali, illustrazioni e disegni, sono meramente indicative e non contrattuali e riferite a modelli standard dei motoryacht del cantiere aggiornate alla data di
emissione della Brochure. Le uniche indicazioni tecniche o descrizioni valide sono quelle relative alla specifica imbarcazione che sarà oggetto di acquisto. Le uniche indicazioni contrattualmente valide
sono contenute nel contratto di vendita. Questo documento si basa sulle informazioni disponibili al momento della sua pubblicazione. Malgrado l’impegno posto ad assicurare la maggior accuratezza
possibile, le informazioni in esso contenute possono non coprire tutti i dettagli e le modifiche tecnico-commerciali intervenute successivamente al momento della stampa, o descrivere caratteristiche
non presenti, ovvero non prevedere tutte le ipotesi che potrebbero verificarsi. Eventuali illustrazioni, fotografie, schemi ed esempi mostrati nella brochure sono intesi unicamente ad illustrare il testo.
A causa delle diverse caratteristiche di ciascuna imbarcazione, il cantiere declina ogni responsabilità per l’uso effettivo in base alle applicazioni illustrate.
This Brochure shall not constitute in any circumstance whatsoever any offer by the Shipyard to any person or be incorporated into any contract. Any and all information contained in this Brochure,
including without limitation all technical data, performance, illustrations and drawings, are just a rough guide and they are not contractual and refer to standard models of motor yachts built by the
Shipyard and have been updated by the shipyards as of the date of issue of the Brochure. Therefore the only indications binding on the seller are contained solely in the sale agreement and in the
relevant specific manual. This Brochure is based on information available at the date of issue. Notwithstanding all efforts to insure accuracy, the information contained in the Brochure may not cover
all details, technical-commercial changes subsequent to the date of issue, nor accurately foresee or report all possible scenarios. Displays, photos, schemes, designs or examples contained in this
brochure are solely and esclusively reproduced to higlight the information contained. Due to the different characteristics of each yacht, the Shipyard declines any and all liability for any use thereof
on the basis of the information contained in this Brochure.
Via M. Coppino, 104 - 55049 Viareggio - LU - Italy - tel. +39 0584 3821 - fax +39 0584 396232 - www.benettiyachts.it
