Brink layout

4637
quality
linked to
Permanently
Type:
Sebring (convertible); 2007->
Avenger; 2007->
Make: Chrysler / Dodge
Fitting instructions
M6x20
11Nm
M12x120
75Nm
9516734
9516735
9516737
9516736
9516738
M12x40
75Nm
4637/50
9078022
4637/6L
4637/4
9516736
9516737
9520064
9516735
9516734
9531242
M12x90 (10.9)
110Nm
4637/6R
9535315
9077070
9516738
M12x40
75Nm
M12x120
75Nm
© 463770MN/27-08-2007/1
© 463770MN/27-08-2007/22
© 463770MN/27-08-2007/21
37
46
(1x) M6x20
(6x) M12x40
(2x) M12x90 (10.9)
(6x) M12x120
(1x) M6 (self-locking
Flange Nut)
(1x) 25x5 L=80mm
(2x) Filling plate
(2x) Spacer
(2x) Spacer
(2x) Spacer
(14x) M12 (10) (selflocking Flange Nut)
4637
© 463770MN/27-08-2007/2
Couplingsclass: A50-X
euro
tested
10
18
D-Value : 9,1 kN
Approved
Approved
19
Approved
e11 00-6364
94/20/EC
kg ?
150
kg
RAYMOND
8.8
10.9
8
MODIFICATION?
10
© 463770MN/27-08-2007/3
© 463770MN/27-08-2007/20
Dispositivo di traino tipo:
Per autoveicoli:
Tipo funzionale:
4637
Chrysler Sebring (convertible) / Dodge Avenger; 2007->
Classe e tipo di attacco:
A50-X
Omologazione:
e11 00-6364
Valore D:
9,1 kN
Carico Verticale max. S:
150
Larghezza rimorchiabile per Caravan e T.A.T.S.: 2,45m vedere CARTA di CIRCOLAZIONE VEICOLO (motrice) + 70 cm = ..arrotondare ai 5 cm
superiore (vedi D.M.28/05/85)
vedi carta di circolazione dell’ autoveicolo
Massa rimorchiabile:
Per verificare l’idoneità del dispositivo di traino omologato a norma CEE
94/20, all’installazione sulla vettura su cui si intende procedere al montaggio, compilare la seguente formula (se necessario declassare la
massa rimorchiabile):
L 9,1 kN
dove: T= Massa Complessiva Max. della motrice (in kg)
C= Massa Rimorchiabile Max. della motrice (in kg)
DA COMPILARE PER IL COLLAUDO
DICHIARAZIONE DI CORRETTO MONTAGGIO: la sottoscritta Ditta dichiara di aver montato in maniera corretta ed in conformit⁄ alle prescrizioni sia del costruttore del veicolo che del costruttore del dispositivo stesso il seguente dispositivo di attacco meccanico:
TIMBRO e FIRMA
tipo:..........................................................................................
Il dispositivo di attacco sopra indicato è stato installato su autoveicolo
modello:...................................................................................
targa:........................................................................................
Data:.........................................................................................
Si dichiara inoltre di aver informato l’utente del veicolo sull’USO e MANUTENZIONE del dispositivo stesso.
© 463770MN/27-08-2007/19
0km
1000km
+
NOTE:
