Application Note, Working with SiteManager SMS and Emails Alerts

Transcript

Application Note: Working with
SiteManager SMS and Email Alerts
This document provides an overview of the different Alert mechanisms support by a Secomea SiteManager hardware unit.
Final draft version: b2.0, December 2014
Applicable to GateManager and SiteManager version 5.8 or newer
(This draft version, is still undergoing the final Q&A, and maybe subject to corrections)
Table of Contents
1.
Introduction
4
1.1.
Alert trigger methods:
4
1.2.
Alert message gateway options:
4
1.3.
Receiving SMS messages, sent to the SiteManager:
5
1.4.
Nice to know about Alert messages
5
2.
Sending Email Alerts transparently via SiteManager
6
2.1.
Using SiteManager as SMTP gateway for sending Email messages via GateManager.
2.1.1.
Setup the mail client on your Device or PC
2.1.2.
Setup SiteManager on a Secomea hosted server
2.1.3.
Setup SiteManager if you are using your own GateManager
2.1.4.
Using SiteManager as transparent Router/Gateway for Email messages
6
6
6
7
8
2.2.
Scenarios – Transparent Email sending
2.2.1.
Sending Emails via Corporate network (Uplink1)
2.2.2.
Sending Emails via 2G/3G network (Uplink2) – model xx39 only
8
8
8
2.3.
Sending Emails via Routing Agent
9
2.4.
Sending Emails via Port Forwarding Agent
9
3.
SiteManager Local Alerts using URL or UDP/TCP Script (Ethernet port)
10
3.1.
Format for sending SMS or Email messages from Ethernet device
3.1.1.
Conditions for Device connections
3.1.2.
Secomea proprietary Alert command format:
3.1.3.
The SMS Compatibility mode format
3.1.4.
Connection timers
3.1.5.
Sending messages using a WEB Browser (URL)
3.1.6.
Sending messages using HTTP requests
10
10
11
11
12
12
12
4.
SiteManager Local Alerts using AT commands via (Serial port)
14
4.1.
Script for sending SMS or Email messages via Serial port
4.1.1.
Standard AT-Command format for sending messages:
4.1.2.
Secomea Proprietary AT-Command format for sending Alerts:
14
14
14
5.
SiteManager Local Alerts triggered by Digital Input ports
16
5.1.
Enabling Digital Input Alert
5.1.1.
Disabling default function of Input1 (GateManager Access control)
16
17
6.
SiteManager local Alert Scenarios
19
6.1.
Sending Email locally via Corporate network (Uplink 1) port
6.1.1.
Sending Email locally via 2G/3G network (Uplink 2) port – xx39 models only
6.1.2.
Sending Email via GateManager (Uplink 1 or 2)
6.1.3.
Sending SMS locally via 2G/3G network (Uplink2) port – xx39 models only
6.1.4.
Sending SMS via GateManager (Uplink 1 or 2)
19
20
20
21
22
7.
Appearance of Emails generated by local Alerts
23
8.
GateManager controlled Alerts (vs. Local Alerts)
25
8.1.
Configuring Input port triggered GateManager alerts
25
8.2.
Create GateManager alert
26
Page 2 of 42
8.2.1.
8.2.2.
Associate Alerts with recipients
Associate GateManager alerts with selected SiteManager
27
29
9.
Reading incoming SMS messages from SiteManager
30
9.1.
Reading SMS messages using Ethernet (TCP)
9.1.1.
Reading SMS messages using a TCP session
9.1.2.
Reading SMS messages using a WEB Browser (URL)
9.1.3.
Reading SMS messages using HTTP requests
30
30
31
31
9.2.
Reading SMS messages using a Serial connection (AT-Commands)
9.2.1.
Testing SMS messages using HyperTerminal for Windows
32
33
Appendix A, SMS Compatibility mode examples
34
Testing Compatibility mode SMS from a Siemens PLC
34
Appendix B, Enable Mail Relay, Own GateManager
40
Appendix C. Configuring devices to use SiteManager as route
41
Method 1: Assign SiteManager as default Gateway
41
Method 2: Configure a local static route
41
Method 3: Inserting a route into the corporate firewall
41
Notices
42
Page 3 of 42
1.
Introduction
The SiteManager appliances support a variety of Alert mechanisms. Alerts
can be triggered by an Input port, Serial port (AT commands) or Ethernet
(URL or UDP/TCP commands).
The resulting Alerts can be sent either directly from the SiteManager via
SMS (for models with integrated modem) or Email, or the Alerts can be sent
via the GateManager either as SMS (if the GateManager has SMS enabled)
or as Email.
1.1. Alert trigger methods:
Devices installed locally to the SiteManager, can use it to send Alert messages by the following trigger methods.
 TCP/UDP – with an Ethernet connection to the SiteManager an SMS or
Email can be send by establishing a TCP session from the PLC to a port
(default) 26864) on the Uplink or DEV interface and send a message
such as: /+4511223344/Tank level low.
 Digital Input ports – on the SiteManager WEB interface you can configure the GateManager > Alert menu to send a static text to a mobile number or email or list of recipients when the Input1 or Input2 ports goes ON
or OFF.
 Serial Port – by using AT-Commands you can, with a Serial connection
from your PLC, trigger the SiteManager to send a SMS or an Email such
as: AT+CMGS=+4511223344 CR Tank level low ctrl+z
 HTTP browser – for testing and troubleshooting you can use a web
browser to send an SMS or Email message, by typing e.g. the following
in the address bar from a PC placed on the Uplink or DEV side of the
SiteManager:http://172.16.16.187:26864/SMS/+4511223344/testing_SM
S
 HTTP Request - You can issue a GET or POST HTTP request to the
SiteManager to send an SMS.
1.2. Alert message gateway options:
Alerts triggered by the above mentioned methods, can be submitted by different methods:
 Using GateManager as Gateway – The SiteManager can be configured
to use the GateManager as gateway for messages triggered by the
above mentioned methods. Note that SMS services must be enabled on
the GateManager to allowing sending of SMS.
 Using SiteManager as Gateway - The SiteManager can be configured
to send Email and SMS messages triggered by the above mentioned
methods from the local Uplink interfaces. Note that it requires an SMTP
settings to be entered in the SiteManager, and that local SMS messages
are only supported by SiteManager models with integrated modem (xx39
models)
 SMTP Relay – A PLC supporting integrated SMTP Client uses the
SiteManager’s DEV port as email gateway, and the SiteManager will relay the Email via the GateManager’s mail service. Such messages are
not logged in the GateManager audit log.
 SMTP Routing – A PLC supporting integrated SMTP Client uses the
SiteManager’s DEV port for routing the email to a SMTP server on the
Uplink side of the SiteManager. Such messages are not logged in the
GateManager audit log.
Page 4 of 42
1.3. Receiving SMS messages, sent to the SiteManager:
Devices installed locally to the SiteManager, can read SMS messages that
have been sent to the SiteManager’s integrated Uplink2 2G/3G modem
(xx39 models only), by the following methods:
 TCP – with an Ethernet connection to the SiteManager a PLC can read
the SMS messages queued on the SiteManager, by creating a TCP connection to the SiteManager’s Alert port (default 26864) and send the text:
/LIST/ALL
 Serial port – by using an AT-Command you can read the SMS messages queued on the SiteManager by the following line command:
AT+CMGL=ALL
 HTTP – for testing and troubleshooting you can use a web browser to
read the queued SMS messages, by typing the following in the address
bar: http://172.16.16.187:26864/SMS/LIST/ALL
 HTTP Request - You can issue a GET or POST HTTP request to the
SiteManager to send an SMS.
1.4. Nice to know about Alert messages
 SMS messages will be sent also when the SiteManager is in SMSWakeup mode (not connected to GateManager).
 Sending Email or SMS messages locally does not require the
SiteManager to be connected to a GateManager.
 SMS or Email messages will be sent also when the 3G/UMTS connection
is in use by another external connection, such as a LinkManager.
 The last 10 messages are stored on the system while old messages are
automatically deleted.
 All messages are cleared after a reboot/repower.
 To use Serial AT-Commands you must set the serial port to SMS Modem
(SiteManager menu: System > Serial > SMS Modem). Also if using the
AT-Commands for sending email messages.
 When the Serial port is used as SMS Modem it cannot be allocated a Serial agent also.
 All AT-Commands must be in capital letters.
 The maximum size of a SMS message is 160 characters
Page 5 of 42
2.
Sending
Email
SiteManager
Alerts
transparently
via
If a device is capable of sending email directly via a built-in mail client, you
can configure the SiteManager to forward or route the mails to a SMTP
server directly or via the GateManager connection.
Note that Alert emails that are sent transparently through the SiteManager
are not registered in the GateManager Audit log.
2.1. Using SiteManager as SMTP gateway for sending Email
messages via GateManager.
NOTE: This illustration shows a SiteManager connected via Uplink1 (Ethernet). The connection to the GateManager can, however, be either Uplink1 or
Uplink2 (2G/3G).
ALERT Heart beat
URL or UDP/TCP Script
Serial AT commands
Digital Input trigger
SMS Message
Status heart beats
Status monitoring
PLC/HMI
Ethernet
The SiteManager does NOT function as a SMTP server. It only relays the
email back to the GateManager, and relies on the GateManager to relay it
further to a SMTP server.
The SiteManger does NOT send traffic directly through the corporate firewall
and the customer’s firewall is not as risk of becoming source for mail traffic
generated by the device. The source for the email will be the GateManager
and it is therefore also vital that it is not abused (refer to Secomea’s terms of
use).
The SiteManager will NOT check the source addresses of devices that attempt to use it for relaying, but will allow relaying for any device on the DEV
side. So make sure that the relay function is used in a controlled environment.
2.1.1. Setup the mail client on your Device or PC
The device or PC that should send emails via the SiteManager must be located on the DEV side of the SiteManager.
Just specify the SiteManager’s DEV1 IP address as SMTP server in your
email client.
NOTE: the mail relay feature does not support encryption or connection to
SMTP servers that require login credentials.
2.1.2. Setup SiteManager on a Secomea hosted server
Page 6 of 42
In order to use the SiteManager as Mail Relay server in conjunction with
Secomea’s hosted GateManager servers you must enter the SiteManager
menu GateManager  Server Relay and create the following Server Relay:
The server address (MAIL), corresponds to a symbolic name on the
GateManager server that directs the mails to a SMTP server.
The Server Virtual address should just specify the SMTP port DEV1:25 (assuming DEV1 on the SiteManager is used). No other port than 25 can be specified.
Note that the GateManager is likely configured to not “Auto-Attach” the Relay
definition. To manually attach, locate the Server Relay for the SiteManager and
select Attach here.
You should now see the Server Relay definition turn IDLE:
2.1.3. Setup SiteManager if you are using your own GateManager
When using your own GateManager you can follow the same procedure as
in section 2.1.2 but you need to ensure that the GateManager is setup to
support the MAIL relay alias.
Page 7 of 42
Refer to Appendix B for configuring the GateManager settings for supporting mail relaying.
2.1.4. Using SiteManager as transparent Router/Gateway for Email messages
You can use the SiteManager’s ability to function as a plain router for devices on the DEV side of the SiteManager.
2.2. Scenarios – Transparent Email sending
2.2.1. Sending Emails via Corporate network (Uplink1)
This scenario requires that the PLC has access to a corporate mail server on
the Uplink side. Note that there may be restrictions to relaying on such a
server, and that emails are sent with the customers SMTP server as source,
but still with the Email address specified by the device. You may have to
adapt the email to match the SMTP server’s mail domain, in order to avoid
blacklisting and spam filters. In any case be careful about using this solution,
as you device emails could be cause for blacklisting the corporate mail server, and thus affecting all mail users at the company.
SMTP (email) traffic
ALERT Heart beat
Serial AT commands
SMS Message
Status heart beats
Status monitoring
PLC/HMI
Ethernet
2.2.2. Sending Emails via 2G/3G network (Uplink2) – model xx39 only
This scenario will use the ISPs SMTP server.
Page 8 of 42
ALERT Heart beat
Serial AT commands
SMS Message
Status heart beats
Status monitoring
PLC/HMI
Ethernet
2.3. Sending Emails via Routing Agent
You can create a Routing agent in the SiteManager, and specify the devices
in the DEV network that should be allowed to access the Uplink side.
In this example Routing is allowed for the addresses 172.16.16.223 and
172.16.16.225. You can define a maximum of three devices.
The device will address the IP address of a SMTP server on the Uplink side
of the SiteManager, and therefore need to know that the SiteManager’s DEV
address is the gateway to that network. Refer to the Appendix C for details
on setting a gateway on a device.
Note that the SMTP server may limit access to specified devices or IP addresses. In this case the source address will be the local Device address.
2.4. Sending Emails via Port Forwarding Agent
You also have the option to create a Forwarding agent in the SiteManager,
and devices on the DEV side will address the SiteManager’s DEV port as
SMTP server address. For this you need to know the IP address and port
number of the target SMTP server.
There are various ways to configure the forwarding rule, depending on how
strict you want to limit access.
In this example a forwarding rule is applied to the DEV1 port IP 10.0.0.1,
which forwards TCP port 25 to the SMTP server at IP address
172.16.17.160 on the Uplink side.
Page 9 of 42
Note that the SMTP server may limit access to specified devices or IP addresses. So you may have to apply the Uplink Source Translation parameter
(+TUP) to the forwarding rule, which will source NAT the connection and let
the SMTP server allow access for the SiteManager’s Uplink address as
source for the mail connection.
For more information on creating forwarding rules, refer to the SiteManager
online help and the separate guide “Using the Forwarding- and Routing
(SCADA) Agents on SiteManager”.
3.
SiteManager Local Alerts using URL or UDP/TCP
Script (Ethernet port)
3.1. Format for sending SMS or Email messages from Ethernet
device
3.1.1. Conditions for Device connections
In the GateManager > Alerts menu in the lower section, you find the options
related to the TCP/UDP formatted Alert commands.
 The port numbers specifies the ports on which the SiteManager will listen
for UDP/TCP commands.
 The Alert Recipient is used as default recipient only when the script does
not contain an SMS or Email recipient.
 The Alerts User Name and Password are used for limiting UDP/TCP requests from devices that includes the User Name and Password specifies
a User Name and/or password that match the values of these fields.
To further ensure that only a known device, such as a PLC or HMI, can use
the alert services you must create an agent for the device – any agent will
Page 10 of 42
do, and the device can be on either the DEV- or UPLINK network. In the example below the Siemens PLC has the IP address 172.16.16.191:
3.1.2. Secomea proprietary Alert command format:
The following syntax can be used for sending an alert by TCP or UDP to the
SiteManager:
/UserName/PassWord/MobilNumber/AlertText
UserName - The User name must match the configured value in the Alert
page see above.
PassWord – The password must match the configured value from the Alert
page (see above).
MobileNumber – The mobile phone number intended for the message.
Country code can be included but is not required.
AlertText.
Example 1:
/+4511223344/Message text 1 to be send.
Example 2:
/11223344/”Message Text 2 to be send”
Example 3:
/<[email protected]>/Message text 3 to be send.
Example 4, when no recipient number or Email is specified, the number
specified as “Alert Message Recipients” on the SiteManager Alert page is
used (if not filled, the message will be discarded):
/”Message Test 4 to be send.”
Example 5, when Agents Alert User name and Password are specified in the
SiteManager Alert page is filled, the values must be entered into the command (if not, the message will be discarded)::
/User1/pass1234/+4511223344/Message text 5 to be send
Or if forcing use of the Agent Alert Recipient settings in the SiteManager
configuration:
/User1/pass1234/0/Message text 5 to be send
/User1/pass1234//Message text 5 to be send
3.1.3. The SMS Compatibility mode format
The SiteManager SMS Compatibility mode format is to a large degree compatible with the SMS messaging script format specified for the Siemens
Scalance modems, and published on the Internet:
Page 11 of 42
"http://support.automation.siemens.com/WW/llisapi.dll?func=cslib.csinfo&lang=en&ob
jid=54361177&caller=view"
In most cases the SiteManager will support the programming blocks based
on this format.
Compatibility mode format:
UserName#PassWord#CommandCode#Seq-Num;Callnumber;Message:
No leading character and the separator here is the number sign # and ; - the
message is terminated with a colon ‘:’
Example 1: User1#Pass1234#105#01;+4512312344:
UserName – User name must match the configured value from the Alert
page (see previous chapter). Maximum character length is 10.
PassWord – Password must match the configure value from the Alert page
(see previous chapter). Maximum character length is 10.
CommandCode – This is always 105 and must not be set different.
Seq-Num – The sequence number is currently not supported and should be
01 and must not be set different.
Callnumber - Call number of the SMS recipient. Limited to 40 characters. International prefix (+45) can be included but is not required.
Message – SMS messages with the maximum of 160 characters.
‘:’
- The message is ended with a colon ‘:’
3.1.4. Connection timers
The Alert is transmitted immediately when the TCP session from the device
that request the alert transmission is closed. If the device does not close the
TCP session, the message will be send within 3 seconds after the
SiteManager has received the complete message. If the device has not
closed the connection within 30 seconds, the SiteManager will force closing
of the session.
3.1.5. Sending messages using a WEB Browser (URL)
for testing and troubleshooting you can use a web browser to send SMS and
Email messages, by typing e.g. the following in the address bar:
http://<address of the SiteManager>:<port>/SMS/<number>/<text message>
Example 1:
http://172.16.16.187:26864/SMS/+4511223344/testing_SMS
Example 2:
http://172.16.16.187:26864/SMS/%[email protected]%3E/testing_SMS
NOTE: “<” and “>” must be entered with their hex values %3C and %3E respectively. Also note that the URL specifies SMS also for Email. This is intentional.
3.1.6. Sending messages using HTTP requests
Note: This feature is experimental, and is subject for elaboration in a future
version of this guide. Please contact your local representative or [email protected] for more information.
To send an SMS via HTTP request, use
GET /SMS/number/messsage_text
POST /SMS/number (contents is raw sms message text)
Page 12 of 42
Optional /username/password must follow /SMS par in URL.
Page 13 of 42
4.
SiteManager Local Alerts using AT commands via
(Serial port)
With a serial connection (RS232) between the PLC and the SiteManager you
can use the SiteManager as serial modem for sending SMS and Email messages using the standard AT-command set.
Enable serial Alert messaging system by setting the Serial interface to SMS
Modem (also if you intend to send email messages generated by AT commands):
Select System > Serial and set Protocol = "SMS Modem"
NOTE: When enabling SMS Modem, the Serial port cannot be allocated a
Serial agent
4.1. Script for sending SMS or Email messages via Serial port
4.1.1. Standard AT-Command format for sending messages:
AT+CMGS=<recipient><CR><message>< ctrl-z>
<recipient> – the mobile number (with or without the international prefix) or
email intended for the message.
<CR> – (Hex:0D)Carriage Return
<message> – The text message to be transmitted (Max 160 char).
<Ctrl-z> - (Hex:1A)ends the message string.
4.1.2. Secomea Proprietary AT-Command format for sending Alerts:
AT+SMS=<recipient>/<message><CR>
This format might be easier to implement in higher level programming.
<recipient> – the mobile number (with or without the international prefix) or
email intended for the message.
/ - “forward slash” separates the recipient and the message string.
<message> – The message string to be transmitted (Max 160 char).
<CR>
- (Hex:0D) Carriage Return ends the message string.
IMPORTANT!
Page 14 of 42
The AT+ portion of the command must be transmitted within half a second or
it will not be recorded as a command by the SiteManager.
After the AT+ command you have 5 seconds to send the remaining part.
Page 15 of 42
5.
SiteManager Local Alerts triggered by Digital Input
ports
The SiteManager has two Digital Input ports that can be used for triggering
SMS messages. Both On and Off states can trigger a specific text string.
Refer to the guide "SiteManager xx29/xx39 - Working with I/O Ports" for details on electrical details and wiring.
By entering script commands in the "Alert Recipient" field, you can enable
the SiteManager to send the message to multiple recipients and even specific recipients depending on the time of day or week. Refer to the online help
for details about the scripting format.
5.1. Enabling Digital Input Alert
Select the menu GateManager > Alerts, and ensure that Alert mode is Enabled:
Input Alert state – Enable and set the state of the input alert to be triggered.
State can be ON, OFF or both.
Note: That Input 1 is default assigned to control GateManager access. Refer
to next section 5.1.1 for information on how to disable this, so you can use
Input 1 for other purposes.
Alert Recipients – The Mobile numbers or email addresses of the recipient(s). More numbers must be separated by comma ‘,’ colon ‘:’ or space.
Email addresses should be entered in < >. In this field you can also enter
script commands ref. Input Alert Scheduling below.
Alert ON Text – Here you can specify the alert text sent when the INPUT
goes ON (and you have requested an alert for "ON" state).
Page 16 of 42
Alert OFF Text - Here you can specify the alert text sent when the INPUT
goes OFF (and you have requested an alert for "OFF" state).
Alert Scheduling - As mentioned above, it is possible to define an Alert
Schedule to control which mobile numbers will receive an alert at different
times of day and week.
For example, if you have a day-time number 11223344, a night-time number
55667788, and a weekend number 99009900, you can enter the following
schedule in the relevant Alert Recipient field. Each of the {...} blocks specifies a time frame for the following recipient(s):
{m-f 6:30-17} 11223344 {m-th 17-6:30, fr 17-24} 55667788 {} 99009900
You read this from left to right as follows: From Monday (m) to Friday (f) at
6:30 to 17:00, call 11223344; or from Monday to Thursday (th) at 17 to 6:30
next morning, and on Friday from 17 to midnight, call 55667788; if no preceding numbers are called, then call 99009900.
As you can see the last {} form specifies "the remaining periods".
Some details:
 Time-of-day is specified as hour or hour:minute, using 1 or 2 digits: H,
HH, H:MM, HH:MM
 24 hour clocks are used, 24:00 equals 0:00 the next day.
 Weekdays are specified as one or two letters: m mo tu w we th f fr sa su
 Ranges are specified as m-f and lists as m,w,f-su
 Times and dates follows the UTC time zone (unless you specify otherwise in menu System > Time).
5.1.1. Disabling default function of Input1 (GateManager Access control)
The Input 1 port is default assigned to control GateManager access. Setting
this port ON will trigger your configured Input1 Alert, but will also disconnect
the GateManager connection, which may not be desired.
To verify that the default function is enabled GateManager Action will read
“Toggle GateManager Access”
Enter the menu GateManager > General, and select More >>
Page 17 of 42
Change the Input1 Action to None
Note: You can also change it to Trigger Input1 if ON/OFF, which will make
the trigger also appear on the GateManager, where it can be controlled by
the “GateManager controlled Alerts” ref. section 8. This will not affect the
functionality for the local Alert you have configured for Input1.
Page 18 of 42
6.
SiteManager local Alert Scenarios
6.1. Sending Email locally via Corporate network (Uplink 1) port
The advantage of this solution is that the Email is sent also when no
GateManager connection is present.
But they may be restrictions to relaying on such a server (e.g. requirement
for login, or accept for the source IP), and that emails are sent with the customers SMTP server as source, but still with the Email address specified by
the URL, UDP/TCP script or Input trigger fields in the SiteManager. You
should be careful about using this solution, as you device emails could be
cause for blacklisting the corporate mail server, and thus affecting all mail
users at the company.
ALERT Heart beat
Serial AT commands
SMS Message
Status heart beats
Status monitoring
Ethernet
COM
RS/232
PLC/HMI
I/O
This scenario requires the following setup of Alert Gateway (Menu
GateManager > Alerts):
And also that that you configure local SMTP settings that corresponds to the
local SMTP server you want to use.
Page 19 of 42
Refer to the online help for details on the parameters
6.1.1. Sending Email locally via 2G/3G network (Uplink 2) port – xx39 models
only
The advantage of this solution is that the Email is sent also when no
GateManager connection is present.
But they may be restrictions to relaying on such a server (e.g. requirement
for login, or accept for the source IP).
ALERT Heart beat
Serial AT commands
SMS Message
Status heart beats
Status monitoring
Ethernet
COM
RS/232
PLC/HMI
I/O
This scenario requires the same configuration settings as explained in the
previous section.
Important to understand is that there is only one set of SMTP settings. So if
the SiteManager is doing failover between Uplink1 and Uplink2, it will only be
able to send Email messages when connected to the Uplink for which the
SMTP parameters correspond.
The Email will be sent using the recipient email address as sender (e.g. if
sent by [email protected], the sender will be [email protected] also), so the
recipient will identify the message based on its subject or body text. See 7
for details on the message appearance.
6.1.2. Sending Email via GateManager (Uplink 1 or 2)
NOTE: This illustration shows a SiteManager connected via Uplink1 (Ethernet). The connection to the GateManager can, however, be either Uplink1 or
Uplink2 (2G/3G).
Page 20 of 42
ALERT Heart beat
Serial AT commands
SMS Message
Status heart beats
Status monitoring
Ethernet
COM
RS/232
PLC/HMI
I/O
The Email will be sent with the GateManagers sender domain as sender
(e.g. [email protected]), so the recipient must be able to recognize the email based on its subject or body text. See section Error! Reference source not found. for details.
6.1.3. Sending SMS locally via 2G/3G network (Uplink2) port – xx39 models
only
ALERT Heart beat
Serial AT commands
SMS Message
Status heart beats
Status monitoring
Ethernet
COM
RS/232
PLC/HMI
I/O
Page 21 of 42
6.1.4. Sending SMS via GateManager (Uplink 1 or 2)
The advantage of this solution is that all SMS messages are logged on the
GateManager, and SMS submission is supported also by SiteManagers
without integrated modem (xx29 models)
ALERT Heart beat
Serial AT commands
SMS Message
Status heart beats
Status monitoring
Ethernet
COM
RS/232
PLC/HMI
I/O
This setup requires that the GateManager supports SMS, and that SMS has
been enabled for the Domain in which the SiteManager is connected. You
can check the availability of SMS in the SiteManager menu GateManager >
Alerts.
Page 22 of 42
7.
Appearance of Emails generated by local Alerts
When sending an Email using UDP/TCP Scripts, URL or using the Input trigger text field in the SiteManager, the final formatting will depend on the setting of the Email Alert Gateway and Alert Identification settings in the
GateManager > Alerts menu in the SiteManager.
In the following examples, make notice of the settings in the SiteManager,
and, the “from” address and the Email Subject, which are not controlled by
the Email string. In all examples the message could have been sent using
the following URL string:
http://172.16.17.138:26864/SMS/%[email protected]%3E/test_MAIL
or as UDP/TCP Script:
/<[email protected]>/test_MAIL
or as specified for an Input port trigger configured in the SiteManager:
Example 1
Settings in SiteManager
Resulting Email:
Example 2
Resulting Email:
Example 3
Page 23 of 42
Resulting Email:
Page 24 of 42
8.
GateManager controlled Alerts (vs. Local Alerts)
The GateManager monitors and gets updates about the status of a
SiteManager based on the persistent connection with the SiteManager. Status of the SiteManager itself can be subject for GateManager alerts, based
on the availability of the connection.
But GateManager will also receive event updates from the SiteManager on
equipment connected to the SiteManager and configured as agents or if a
digital Input port is triggered.
In these cases the SiteManager is not itself sending or executing the Alert;
instead the GateManager is responsible for this logic.
ALERT message
Serial AT commands
SMS Message
Status heart beats
Status monitoring
Ethernet
COM
USB
PLC/HMI
I/O
8.1. Configuring Input port triggered GateManager alerts
By default a SiteManager is configured to not send Local Alerts, and the
configuration would look like this:
You will notice that the Alert status table shows something called
“GateManager Action”, which means triggering Input1 will by default disconnect the GateManager connection. This will not generate a status message
to the GateManager, or generate an alert.
Page 25 of 42
Hint: If it is actually desired to sent an alert when the GateManager access
is disconnected using Input1, you can just make an Alert definition on the
GateManager based on the SiteManager going offline. See section ??
If you want to control in more details which Input triggered signals should result in an alert trigger to the GateManager, you should enter menu
GateManager > General and click More >>
Now you can control for both Input1 and 2 when a signal should be sent to
the GateManager based on triggering of Input 1 or 2.
8.2. Create GateManager alert
To create GateManager alerts you need to have a GateManager Domain
Administrator account (PREMIUM account).
When logged in ensure that the Alert icon above the tree has a blue background. Now either right click the domain and select “Create Alert”, or select
the Alert tab to the right, and select the plus sign:
Page 26 of 42
Select a meaningful name for the Alert, as this will become the Alert message text. You can now specify for instance to trigger the alert when Input2
is ON.
Another idea was to trigger the alert when the SiteManager itself disconnects
Note in this example that the Alert is not triggered until after 300 seconds.
This will ensure that e.g. a brief repower of the SiteManager at the location
will not activate the Alert.
HINT: This type of status Alert can be used for any type of appliance including software based SiteManagers (SM-E), LinkManagers and Agents
8.2.1. Associate Alerts with recipients
Alerts recipients can be in form of either:
 Email addresses entered directly into the “Send to” field (enter multiple
email addresses separated by comma).
 A Mobile phone number entered directly into the field (only one can be
entered). This requires that the GateManager supports SMS, and that
SMS services have been enabled for the domain in which the
SiteManager is attached.
 An Account, and its associated Email or SMS.
Page 27 of 42
Read more details in the light bulb
next to the Send to field.
Associating an account with the Alert has the advantage that if the Email or
Mobile number of the account is changed, it automatically have effect on the
alert. In principle you could create a “dummy account”, which only purpose is
to make a single point of edit of the email or mobile numbers for all Alerts.
Associating an account with an Alert is done as follows:
While standing on the Alert, left mouse click and hold on a account, and drag
it into the Send to field of the Alert.
This will associate the account ID with the Alert, and automatically use the
Email for the account as recipient
If you want to use the Mobile number specified for the account to send the
alert as an SMS instead of an Email, you should replace “account” with
“sms” in the Send to field:
Page 28 of 42
NOTE: If specifying “sms” for the account, and a mobile number is not specified for the account or SMS is not supported by the GateManager or SMS
services is not enabled for the domain, the alert will automatically be send to
the account email.
8.2.2. Associate GateManager alerts with selected SiteManager
When you have created an alert you can associate it to one or more
SiteManagers or Agents. This may be for SiteManagers in the same domain
as the Agent, or also for SiteManagers in subdomains if the Agent is specified to also apply to sub-domains, as follows:
Page 29 of 42
9.
Reading
incoming
SiteManager
SMS
messages
from
SiteManager models with integrated modem (xx39 series) allow receiving
and queuing of incoming SMS messages, which can subsequently be read
by a device via the Ethernet ports, or the Serial port.
The last 10 messages are stored in the SiteManager on first-in first-deleted
basis. All messages are deleted on reboot.
NOTE: This section is subject for further details in future version of this
guide. If you are uncertain about the functionality, please address your question to your local representative or Secomea support on [email protected]
9.1. Reading SMS messages using Ethernet (TCP)
ALERT Heart beat
Serial AT commands
SMS Message
Status heart beats
Status monitoring
PLC/HMI
Ethernet
9.1.1. Reading SMS messages using a TCP session
A device can read SMS messages by connecting with TCP on port 26864 on
the SiteManager.
This supplements the normal SMS sending format via TCP:
[ /username/password ] /number/text - send text to number
Command format is:
[ /username/password ] /command[:[:]PORT]/selector
Where command is one of:
 LIST - list headers for selected SMS'es
 READ - print headers and bodies for selected SMS'es (mark as read)
 PRINT - print bodies for selected SMS'es (mark as read)
 DELETE - delete selected SMS'es
and selector is one of:
 ALL - all messages
 READ - read messages only
 UNREAD (or blank) - unread messages only
Page 30 of 42
 NEXT - Reads next unread message (and changes status to read)
num[,num...] - comma separated list of messages numbers
The port entry defines which port the SiteManager will send the data on. If
no port is defined, the SiteManager will respond in the same TCP thread.
One colon means that SM will only make the response connection if there is
any response data to send, while two colons will always make the response
connection, even when the response is empty.
For example, /READ:12345/NEXT will send next message to port 12345 on
the sender's IP - but only if a new message is pending, while
/READ::12345/NEXT will send an empty response to port 12345 if no new
message is pending.
Supported field separators: CR, NL, CRNL, TAB, / $ & and =.
Note that first character in packet defines the separator!
9.1.2. Reading SMS messages using a WEB Browser (URL)
For testing and troubleshooting you can use a web browser to read the
queued SMS messages, by typing the following in the address bar:
http://<address of the SiteManager>:<port>/SMS/<command>
Example:
http://172.16.16.187:26864/SMS/LIST/ALL
9.1.3. Reading SMS messages using HTTP requests
You can issue a HTTP requests to the SiteManager using the following
commands:
 GET /SMS/command/selector
 POST /SMS/command (contents is selector)
Page 31 of 42
9.2. Reading SMS messages using a Serial connection (ATCommands)
ALERT Heart beat
Serial AT commands
SMS Message
Status heart beats
Status monitoring
PLC/HMI
COM
RS/232
With a serial connection (RS232) between the PLC and the SiteManager you
can use the SiteManager as serial modem on which you can read incoming
SMS messages using the standard AT-command set.
Enable serial SMS messaging system by setting the Serial interface to SMS
Modem:
Select System > Serial and set Protocol = "SMS Modem"
Page 32 of 42
NOTE: When enabling SMS Modem, the Serial port cannot be allocated
a Serial agent
Commands supported:
List and read:
AT+CMGL
AT+CMGL=["ALL"|"REC UNREAD"|"REC READ"]
Read:
AT+CMGR=n
Delete:
AT+CMGD=n[,flag] [flag=0..4]
Nice to know:
Receiving an SMS message will generate a +CMTI on the Serial connection.
For example to retrieve SMS number 8 send:
+CMTI: “SM”,8
Note: +CMTI is optional but enabled by default (controlled via +CNMI)
The SiteManager has limited support for the commands:
AT+COPS +CSDH +CMGF +CNMI +CSCA
9.2.1. Testing SMS messages using HyperTerminal for Windows
Examples will follow in a future version of this guide.
Page 33 of 42
Appendix A, SMS Compatibility mode examples
You can download code samples for Siemens TIA and CoDeSys from the
Secomea web site (in the Documentation section).
rd
Please note that files in that section are provided to us by 3 party users.
These files should be seen as “proof of concept”, and do not represent
ready-to-use projects. You can use the files “as-is” or as inspiration.
The files are licensed "as-is". You bear the risk of using it. Secomea gives no
express warranties, guarantees or conditions. Also, please note that
Secomea cannot provide support on the files and their use. “SMS Compatibility mode” has been verified and tested from a Siemens ET 200S PLC, but
it should be possible to implement for any other Siemens PLC with a native
Ethernet adapter.
This screen shot illustrates how a code block for CodeSys verified on a
Wago would look like:
Testing Compatibility mode SMS from a Siemens PLC
The following shows the steps for manually testing SMS from a Siemens ET
200S PLC, using a block defined in TIA portal.
NOTE: This example is not a guide for programming the block, but is only intended for providing the basic idea of the principles for handling SMS from
within a PLC program. Refer to your Siemens documentation for details, or
study the code samples found on the Secomea web site.
Page 34 of 42
1. Go online on the PLC
Page 35 of 42
2. Expand the Program blocks and double click on the SMS module.
3. Double click on the values (in the Start value column) in order to change them.
Make sure that the telephone number to receive the SMS is correct and the
Remote IP address is set to the SiteManagers DEV IP address.
Note that the IP address is entered in HEX (e.g. DW#16#AC180203" =
172.24.2.3)
Page 36 of 42
4. Remember to download to device whenever you have changed something:
Page 37 of 42
5. Because OB1 depends on the value from DB11, OB1 also needs to be compiled and downloaded again. Click overwrite, and Load
6. To send an SMS, double click on CYCL_EXC [OB1]
Page 38 of 42
7. Monitor the data (click the glasses)
8. Set “sms_send” to 1 – REMEMBER to set it back to 0 again right after.
Page 39 of 42
Appendix B, Enable Mail Relay, Own GateManager
Under Server Relay Target Names, add the following entry:
MAIL=x.x.x.x:25
"MAIL" is the symbolic name that is used in the SiteManager (See screenshot in section 2.1.2
“x.x.x.x” denotes the IP address of your mail server or mail relay. This is typically the same as the one configured under Server  Config  Mail Settings.
"25" is the default SMTP port of the relay server. Note that the GateManager
will not support relaying of encrypted mails or relaying to mail servers that
require login credentials.
In this example the corporate server 172.16.14.12 is Mail Relay server for
this GateManager. The mail server must be configured to accept relaying of
mail from the GateManager.
If you want to use the integrated SMTP server of the GateManager you can
enter a local host IP:
MAIL=127.0.0.1:25
Page 40 of 42
Appendix C. Configuring
SiteManager as route
devices
to
use
For a device to use the SiteManager as route based on the Routing agent,
the device needs to know that the SiteManager is the gateway to the other
network.
Method 1: Assign SiteManager as default Gateway
If the SiteManager is configured as default gateway for the device, the device will automatically use the SiteManager as route. If the device does not
already use another device as gateway, you may safely change it to the local IP address of the SiteManager. This would typically only be the case for
devices on an isolated DEV network.
If the device supports DHCP, you can enable DHCP on the DEV port of the
SiteManager and the device will automatically get the SiteManager’s DEV
port as default gateway. If you are concerned that the IP address may
change, you can enter the SiteManager menu DEV > DHCP > Leases and
fix the MAC address of the device to always have a specific IP address assigned.
Method 2: Configure a local static route
If the device is on the Uplink side of the SiteManager, or does not allow changing
its current default gateway, you must configure a static route on the device. Refer
to the documentation of your device for instructions.
If the device is a Windows computer, you can open a command prompt and enter a
static route through the “route” command.
Press “Windows key + R” or go to the start menu and type “cmd” and press
ENTER.
Use the “route” command to add a static route. See example below:
Then configure your software to access the IP address of the devices directly.
Ie. 192.168.12.4 and 192.168.12.5.
Method 3: Inserting a route into the corporate firewall
When the SCADA PC needs access to an IP address not being in the same subnet
as the SCADA PC, it will request the route from its default router. This router is typically the corporate firewall.
You should therefore insert a static route rule in the firewall that routes request to
IP addresses of equipment in the device network to the uplink address of the
SiteManager.
With the example above in mind, the firewall should be configured to forward requests for IP addresses in subnet 192.168.12.0 to the “router” 172.16.15.18.
Page 41 of 42
Notices
Publication and copyright
© Copyright Secomea A/S 2013-2014. All rights reserved. You may download
and print a copy for your own use. As a high-level administrator, you may use
whatever you like from contents of this document to create your own instructions for deploying our products. Otherwise, no part of this document may be
copied or reproduced in any way, without the written consent of Secomea A/S.
We would appreciate getting a copy of the material you produce in order to
make our own material better and – if you give us permission – to inspire other
users.
Trademarks
SiteManager™, LinkManager™ and GateManager™ are trademarks of
Secomea A/S. Other trademarks are the property of their respective owners.
Disclaimer
Secomea A/S reserves the right to make changes to this publication and to the
products described herein without notice. The publication of this document does
not represent a commitment on the part of Secomea A/S. Considerable effort
has been made to ensure that this publication is free of inaccuracies and omissions but we cannot guarantee that there are none.
The following paragraph does not apply to any country or state where such provisions are inconsistent with local law:
SECOMEA A/S PROVIDES THIS PUBLICATION "AS IS" WITHOUT
WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING,
BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE
SECOMEA A/S SHALL NOT BE LIABLE FOR ANY DIRECT, INDIRECT,
INCIDENTAL, CONSEQUENTIAL, OR OTHER DAMAGE ALLEGED IN
CONNECTION WITH THE FURNISHING OR USE OF THIS INFORMATION.
Secomea A/S
Denmark
CVR No. DK 31 36 60 38
E-mail: [email protected]
www.secomea.com
Page 42 of 42

Application Note, Working with SiteManager SMS and Emails Alerts

Transcript

Documenti analoghi

LinkManager Installation Guide

PMP 450m cnMedusa Demonstration Guide

C24_gsm_utenteV1.5-EN

Tiger Demo

UARTDNG200 application note Rev1.0.pub

DI-000-20A30-00A - Leviton Home Solutions

Timed Online Auction Sale of a GE Voluson E8

Information for contacts from the website and the sending of

USB Adapter - Atlantis-Land

Urban planning practice and urban practice at

T1010 English
