Università degli Studi di Pisa
Dipartimento di Informatica
Lesson n.4
DISTRIBUTED HASH TABLES:
AN INTRODUCTION
Laura Ricci
7/10/2014
DHT: An Introduction
Laura Ricci
1
OUTLINE OF THE LESSON

Distributed Hash Tables (DHT)

what is a DHT ?

what are the main functionalities of a DHT?


data addressing

routing

join/leave
DHT instances:

Chord, CAN, Pastry, Kademlia/KAD

DHT applications

Formal tools: modelling Chord routing through Markov chains
Laura Ricci
2
SEARCHING IN P2P SYSTEMS
I have the information „I“.
Where do I store it?
I
?
Informazione „I“
?
Node A
I want to look for
information I Where
do I find „I“?
?
distributed system
Node B
12.5.7.31
berkeley.edu
planet-lab.org
peer-to-peer.info
89.11.20.15
95.7.6.10
86.8.10.18
7.31.10.25

Main problem of a P2P system: content search

In Gnutella: content is stored at the peer sharing it

Internet Node
the main problem, due to the lack of network structuring, is searching.
Where is the content with the desired characteristics?
Laura Ricci
3
SEARCHING IN P2P SYSTEMS
I have the information „I“.
Where do I store it?
I
?
Informazione „I“
?
Node A
I want to look for
information I Where
do I find „I“?
?
distributed system
Node B
12.5.7.31
berkeley.edu
planet-lab.org
peer-to-peer.info
89.11.20.15
95.7.6.10
86.8.10.18



7.31.10.25
Internet Node
A stores an information , B wants to find I, but does not know the location of I
How to organize the distributed system? What are the mechanisms exploited
to decide where the information should be stored and how to find it?
Any solution must take into account:


system scalability. evaluation of the communication overhead and of the
memory needed by any node, as a function of the number of nodes (peers)
system adaptability due to faults and to frequent changes (churn)
Laura Ricci
4
SEARCHING/ADDRESSING




two strategies for content retrieval in a P2P network

searching: guide the search by the value of a set of attributes of the
content

addressing: associate a unique identifier ID to the content (sometimes
called content key) and exploit the ID to address content
the mechanism chosen for searching/addressing influences:

the construction of the overlay

the way the objects are paired with the peers

the efficiency of the content search
in file sharing P2P systems:

searching: for instance implemented thorough aTTL-enahanced floading

note that an unique identifier is associated to the content, but it is
not exploited for retrieving the object. The object is retrieved by
specifying a set of keywords

addressing: Distributed Hash Table
Laura Ricci
5
Addressing:

pair a unique identifier with a
content

exploit the identifier to look up
the content

similar to an URL for web


advantages:

each object is uniquely identified

efficient
object
detection
(logarithmic routing)
disadvantages:

ID computation (hash)

maintaining
the
addressing
structure
Searching:

look for contents by specifiyng the
values a set of key-words
Gnutella 0.4 and 0.6
similar to Google




advantages:

“user friendly”: it does not
require

ID computation

auxiliary structures
disadvanteges

search inefficiency

need of comparing
objects: overhead
Laura Ricci
whole
6
Unstructured Overlay

no addressing: TTL enhanced flooding

no mapping rule to map content to peers

no rule to define the neighbours of a peer: each peer may arbitrarly
choose its neighbours

this does not imply a complete lack of structure...the network may assume
a structure

scale free, power-law, small world,....
Structured Overlay

define an addressing mechanism

overlay topology follows some rule

define a mapping rule to map content to peers

deterministic routing

Distributed Hash Tables (DHT)
Laura Ricci
7
DHT: MOTIVATIONS


Centralized Approach: a server indexing the data

Search: O(1) – “ Content is stored in a centralized server”

Space required: O(N) (N = amount of shared content)

Bandwidth (connection server/overlay): O(N)

complex queries may be easily managed
Fully Distributed Approach: unstructured network

Search: worst case O(N2) - “each node contact each of its neighbours”


Possible optimizations (TTL, identifiers to avoid cyclic paths)
Space Required: O(1)

does not depend on the number of nodes in the system

no data structure to route queries (flooding)
Laura Ricci
8
DISTRIBUTED HASH TABLES: MOTIVATIONS
Analysis of Existing Systems
Communication
Overhead
Flooding
O(N)
Disadvantages:
• Communication overhead
• False negative
?
O(log N)
Does it exist a solution
Which is a compromise between
the two proposals?
O(1)
O(1)
O(log N) Memory
Laura Ricci
Disadvantages:
• Memory, CPU, Required
Bandwidth richiesta
• Fault Tolerance
Centralized
Server
O(N)
9
DISTRIBUTED HASH TABLES: MOTIVATIONS
Scalability: O(log N)
Avoid False negative
Communication
Overhead
Flooding
O(N)
Self Organization : the system automatically
manages
Disadvantage:
• Communication Overhead
• False Negative
 Join of new nodes in the system
 Leave (volunteer/faults)
Distributed
Hash Table
O(log N)
O(1)
O(1)
O(log N) Memory
Laura Ricci
Disadvantage
• Memory, CPU,Required
Bandwidth
• Fault Tolerance
Centralized
Server
O(N)
10
DISTRIBUTED HASH TABLES: GOALS

Main goal is scalability

O(log(N)) hops to look up an information

O(log(N)) entries in the routing table
Routing requires
O(log(N)) steps to reach
the node storing the
information
H(„my data“)
= 3107
1622
1008
709
2011
2207
611
3485
2906
O(log(N)) size of the
routing table of each
node
12.5.7.31
berkeley.edu
planet-lab.org
peer-to-peer.info
89.11.20.15
95.7.6.10
86.8.10.18
7.31.10.25
Laura Ricci
11
DISTRIBUTED HASH TABLES: GOALS

Self adapting with respect to faults, join and leave of new nodes

re-assignment and re-distribution of content for faults or voluntary
leaves from the network

Balancing content among nodes

important to avoid the increase of the search length
Laura Ricci
12
HASH TABLES: BASIC CONCEPTS




value insertion: 0,1,4,9,16,25
hash function
hash(x) = x mod 10
mapping from an input domain of large size
to a smaller output domain
the input domain is too large to
directly exploit the input key as vector
index

a bounded number of collections

search O(1)
Laura Ricci
13
HASH TABLES: BASIC CONCEPTS

Insertion, Elimination, look-up: O(1)

Hash Table: A fixed size array

elements= hash buckets

Hash function: it maps keys to vector elements

Properties of a good hash function:

simple to compute

a uniform distribution of the keys in the hash table
Laura Ricci
14
DISTRIBUTED HASH TABLES: BASIC IDEAS

Distribute the buckets to the peers:



Distributed Hash Tables
collision resistant function
This requires:

a mechanism to define which is
the peer responsible for a bucket

a routing mechanism to find the
peer managing a bucket
Laura Ricci
15
DISTRIBUTED HASH TABLES


A first solution

hash(data) returns the index of a peer

hash function depends on number of
peers

does not work efficiently for inserting
and deleting items: needs to completely
repartition the hash table
The DHT solution:

peers are „hashed“ to a very big
logical space

index data is also „hashed“ to this space

peers are given a set of buckets in this
space

All data falling in a segment is mapped to
the corresponding peer
Laura Ricci
16
DISTRIBUTED HASH TABLES: THE BASIC IDEA



in a DHT, every node is responsible
for the management of one or
more buckets

when a node enters/leaves the
network it passes the bucket
to another node
the nodes communicate among
them to detect the node managing
a bucket

requires
a
communication
mechanism
scalable
and
efficient
all the operations of a classical
hash table are supported
Laura Ricci
17
DISTRIBUTED HASH TABLES: THE BASIC IDEA



The mechanism exploited to detect the peer managing a given bucket
characterizes the DHT
The typical behaviour

a node knows the key of the content it is looking for

routing brings to the node which is the responsible of the bucket
where the key is located

the node which is responsible of that bucket, directly sends the
content or a pointer to the content
Abstraction defined by a DHT

stores (key-value) pairs

given a key, the DHT returns the corresponding value

the DHT pairs no semantics with the pair key/value
Laura Ricci
18
DHT: DISTRIBUTED DATA MANAGEMENT
Nodes and data are mapped in the same address space




an unique identifier is paired

with each peer

with each data stored in the P2P network
a single logic space for data and peers
nodes are responsible for the management of a portion of the
addresses logical space (one or more buckets)
the correspondence between data and nodes may vary due to the
join/leave of the nodes
Laura Ricci
19
DHT: DISTRIBUTED DATA MANAGEMENT
Data store/search

Data search = routing towards the node responsible of that data

Each node maintains a routing table, which gives to the node a partial
view of the system

Key-based Routing: Routing is guided by the knowledge of the unique
identifier(key) of the data which is looked up

False negatives are avoided
Laura Ricci
20
STEP 1: DHT ADDRESSING
The simplest scenario: nodes and content mapped in a linear address
space 0, …, 2m-1
The size of the linear logical address space is >> with respect to the
number of objects to store (es m=160).
A total order is defined on the address space (MOD operations)
For instance, address space may be structured as a logical ring S
Mapping data-logical addresses through a hash function
Hash(String) mod 2m, , for instance Hash(''mydata'')=2313
Laura Ricci
21
STEP 2: MAPPING NODES/LOGICAL ADDRESSES




Each node is responsible of a contiguous portion of the address space (some
buckets).
Data are mapped into the same logical address space of the nodes, through
the hash function

E.g., Hash(String): H(“'MyData“)  2313

Examples: hashing of the file name or of its content
Each node stores information related to the data mapped onto its portion of
the address space
Some replication (redundancy) is often introduced
Laura Ricci
22
STEP 2: MAPPING NODES/LOGICAL ADDRESSES
Each node is responsible of an interval of identifiers
Interval overlapping introduces a level of redundancy
Continuous adaptation
Underlay topology and logical overlay are not correlated
Laura Ricci
23
STEP 3: DATA STORAGE
Direct Storage
Indirect Storage
Laura Ricci
24
STEP 3: DIRECT STORAGE


DHT stores pairs (key,value)
The data is stored, when it is inserted in the DHT, onto the responsible node

such a node is not, in general, the node which has inserted the data into
the DHT
An example: key = H(“Data”) = 3107. Data is stored onto the node which
manages the address portion including the address 3107.
1008
709
611
D
D
1622
D
2011
3485
2207
2906
HSHA-1(''Dato'')=3107
134.2.11.68
Laura Ricci
25
STEP 3: INDIRECT STORAGE



Value = may be a reference to the data (ex: the physical address of the node
storing the content)
The node storing the content may be the node which has inserted the
content into the system
A flexible solution, but it needs a further step to access the data
1008
709
611
1622
2011
3485
2207
2906
HSHA-1(„Dato“)=3107
D
D: 134.2.11.68
134.2.11.68
Laura Ricci
26
STEP 4: ROUTING



search for D may start at an arbitrary node of the DHT and is guided by
key=HASH(D)
each node has a partial vision of the other nodes
Next hop: depends from the routing algorithm

content-based-routing: for instance based on the closeness between the
data and the node IDs of the nodes in the routing table

Value paired with the key: IP address + port of the peer storing D.
Laura Ricci
27
STEP 5: DATA RETRIEVAL
Content Download
Send IP address and port to the requesting peer
If indirect addressing is exploited, the requesting peer download the
content from a third peer.
Laura Ricci
28
DHT: LOAD BALANCING



Main reasons for load unbalance in the distribution of address intervals:

a node manages a bigger portion of the logical address space

solution: exploit an uniform hash function

the address spaces are uniformly distributed among the nodes but the
addresses managed by a node correspond to lot of data

a node manages a lot of queries, because the data paired with the
addresses assigned to it are very popular
Load unbalance implies:

less system robustness

less scalability

O(log N) bounds are not guaranteed
Solutions:

Uniform hash functions

Load balancing algorithms definitions
Laura Ricci
29
DHT: JOINS AND LEAVES
Distributed Hash Table

peers are hashed to a linear space

content are hashed according to the
search key

peers store index data
in their areas
when a peer joins

neighbour peers share their areas
with the new peer
when a peer leaves

the neighbours inherit the
responsibilities for the
the data of the leaving peers

Which neighbours depend from the DHT
Laura Ricci
30
DHT: NODE JOIN






compute the node unique identifier
contact an arbitrary node of the DHT (bootstrap node)
detect the exact point of the DHT where to join (predecessor and
successor node)
assign a portion of the logical address space to the new peer
copy the assigned Key/value pairs (with redundancy)
insertion in the DHT (connect with the proper neighbours)
709
1008
1622
2011
2207

611
2906
3485


ID: 3485
134.2.11.68
Laura Ricci
31
DHT: NODE LEAVE


Voluntary leave of a node

partitioning of its address space to the neighbour nodes

copy key/value pairs to the corresponding nodes

deletion of the node from the routing tables of the other nodes
Node failure


If a node suddenly disconnect from the network, all data stored on it are
lost if they are not stored on other nodes

introduce some redundancy (data replication)

information loss: periodical information refresh
Exploit alternative/redundant routing paths

periodical probing of the neighbour nodes to detect their activity.
When a fault is detected, update routing tables.
Laura Ricci
32
COMPARING DIFFERENT APPROACHES
Approach
Central
Server
Pure P2P
(flooding)
DHT
Memory for
Communication
Complex
each node
Overhead
O(N)
Queries
False
Negatives
Robustness
O(1)



O(1)
O(N²)



O(log N)
O(log N)



Laura Ricci
33
DHT: API

API to access a DHT

content insertion:


content search


GET(key)
replies


PUT(key,value)
Value
The interface is common to several DHT systems
Distributed Application
Put(Key,Value)
Get(Key)
Value
Distributed Hash Table
(CAN, Chord, Pastry, Tapestry, …)
Node 1
Node 2
Node 3
....
Laura Ricci
Node N
34
DHT: APPLICATIONS

DHT offer a generic distributed service for information storing and indexing

The value paired with a key may be


a file

an IP address

or every further data……
Applications exploiting a DHT

DNS implementation

key: host name, value: list of corresponding IP addresses

P2P storage systems: example Freenet, PAST

Define a support for higher level services
……
Laura Ricci
35
CONCLUSIONS
DHT Properties

routing is based on key (unique identifier)

key are uniformly distributed to the DHT nodes

bottleneck avoidance

incremental insertion of the keys

fault tolerance

auto organizing system

simplex and efficient organization

the terms “Structured Peer-to-Peer“ and “DHT“ are often used as
synonyms
Support several applications

The values paired with the keys depend on the application
Laura Ricci
36
DHT: EXISTING SYSTEMS





Chord
Pastry
Tapestry
CAN
P-Grid
UC Berkeley, MIT
Microsoft Research, Rice University
UC Berkeley
UC Berkeley, ICSI
EPFL Lausanne

Kademlia , KAD network of e-Mule...

Symphony, Viceroy, …
Laura Ricci
37

DHT - e-learning - Dipartimento di Informatica

Transcript

Documenti analoghi

determination of thyreostats in bovine urine and thyroid glands by

Microsoft PowerPoint - DP-L03-DesignPrinciples2015.ppt

Evolution and development of the cerebral cortex

Elementary Affine Logic and the Call by Value Lambda Calculus

volcanism and intrusions of the deccan traps, india: geochemistry

p2p storage networks - e-learning

Deformation history of Mauna Loa (Hawaii) from 2003 to 2014

Boring Machines

new mock exam 27 luglio 07

Example of Student or Graduate CV

Is love a tender thing

Architetture e Protocolli nelle Reti Peer-to-Peer

S13-S24 Edizioni ETS Pisa, 2007 S13 Edizioni ETS Pisa

Diapositiva 1 - Fondazione Mondo Respiro
