SMT
screens
and stencils
obtained by
Electroforming
SMT screens and
stencils obtained
by electroforming
The electroforming technology allows to
produce nickel sheets through an extremely
accurate process of galvanic deposition. The
high quality of the product is the result of
nickel growth around three-dimensional
geometries (matrix) obtained by a
photographic process.
This technology is suitable for SMT printing
applications for fine pitch SMD components,
BGA and micro BGA components and also
for wafer bumping applications.
The process
1 - Coating
Fotoresist
Steel sheet
2 - Exposure
UV light
Photographic film
Fotoresist
Steel sheet
3 - Development
Development solution
Fotoresist
Steel sheet
Caratteristiche geometriche delle finestre
Tolleranza dimensionale delle finestre < +/- 10µ
Inclinazione della parete interna < 25µ
4 - Electroplating
Nickel
+
Nickel
electroplating
Steel sheet
-
Advantages
Nickel
electroplating
Steel sheet
Vaiarelli srl - C.so Vercelli, 16
10078 Venaria Reale (Torino) - Italia
Tel. +39 0114070811 - Fax +39 0114070812
www.stv-italia.com e-mail: [email protected]
STV France sarl
Zone d'activité Les Marlières, 59710 Avelin (Lille) - France
Tél. + 33 (0)3 20160008 Fax + 33 (0)3 20961922
www.stv-france.com e-mail: [email protected]
TRADING
5 - Detachment
High dimensional precision
Trapped walls
Low tensile stretch
Very smooth surface
Different thickness available
Good print quality
