A Framework for ECG Signal Processing
based on Quadratic Variation Reduction
Advisor
Prof. Giulio Iannello
Co-Advisor
Dr.Eng. Antonio Fasano
Ph.D. Candidate
Valeria Villani
April 2013
in data 23/04/2013.
A Camillo
Non quia difficilia sunt non audemus,
sed quia non audemus difficilia sunt.
Lucius Annaeus Seneca
in data 23/04/2013.
Abstract
The analysis of the elctrocardiogram (ECG) is the standard diagnostic tool for the
assessment of heart function and the diagnosis of cardiac diseases. Unfortunately,
ECG signal is highly susceptible to several kinds of noise, such as thermal and
electromyographic noise, power-line interference, motion artifacts, and baseline
wander. In this dissertation, a framework for ECG signal processing based on the
notion of quadratic variation reduction is proposed. The quadratic variation is a
consistent measure of variability for vectors or sampled functions.
In recent years, growing interest has been focused on the analysis of single
waves of the ECG, like P-waves or T-waves. Being able to track beat-to-beat
changes of such waves has proven to be helpful in predicting important heart diseases, such as atrial fibrillation (AF). Since single waves have low SNR, they are
commonly analyzed via signal averaging. In this way information about beat-tobeat variability is unavoidably masked or possibly lost. To cope with this problem, in Chapter 3 a smoothing and denoising algorithm for ECG single waves is
proposed, which is based on the notion of quadratic variation reduction. The algorithm is the closed-form solution to a constrained convex optimization problem,
where the quadratic variation enters as a constraint. Numerical results show that
the approach achieves considerable SNR gain over the whole range of practical
input SNRs.
In Chapter 3 the algorithm is successfully applied to the prediction of AF
through the analysis of P-waves beat-to-beat variability. Denoising by quadratic
variation reduction enters in the definition of a metric that measures P-waves variability. The study of the statistics of such a metric allows to discriminate between
AF-prone and healthy subjects.
Narrowband artifacts, such as power-line interference, are another common
i
in data 23/04/2013.
Abstract
kind of noise affecting ECG waves. In Chapter 4 is proposed a joint approach
to denoising and narrowband artifacts rejection. It is achieved by solving a constrained convex optimization problem, where the energy content of harmonic artifacts enters as an additional constraint.
The improvement achieved by the approach based on quadratic variation reduction is notable, and this makes worth its extension to the smoothing of entire
ECGs. However, this is effective if the local structure of the ECG is explicitly
taken into account in the smoothing operation. In Chapter 5 a smoothing and denoising algorithm for entire ECGs is proposed. Smoothing is performed by locally
reducing the variability, i.e., the quadratic variation, of the measured ECG, by an
amount that is inversely related to the local SNR. Numerical results show that the
smoothing performance is significant. The algorithm is favorable also in terms of
complexity, which is linear in the size of the record to smooth.
In the presence of noise and narrowband artifacts, a combined approach based
on joint denoising and artifacts rejection is needed. This is pursued in Chapter 6,
where smoothing and narrowband artifacts rejection are performed jointly combining local characteristics of the ECG and the spectral localization of the artifacts
to reject. Simulation results confirm the effectiveness of the approach and highlight a notable ability to smooth and denoise ECG signals.
Finally, in Chapter 7 the problem of baseline wander removal is tackled. This
is an unavoidable step in any processing of ECG signals. Baseline wander and
ECG have partially overlapping bands in the low-frequency region of the spectrum. This makes its removal difficult without affecting the ECG, in particular
the ST segment, which is related to the diagnosis of acute coronary syndromes.
Due to the in-band nature of this kind of noise, any technique for its removal that
relies on spectral shaping, e.g., linear time-invariant filtering, will unavoidably alter the ST segment. To cope with this problem it is necessary to analyze baseline
noise and ECG components contributing to the ST segment in a domain that is
not the frequency domain. In this regard, the quadratic variation turns out to be
a suitable measure of variability that is not directly related to the frequency domain. In Chapter 7 baseline wander is estimated as the component of measured
ECG with the lowest variability. Comparative analyses show that the approach
outperforms state-of-the-art algorithms and is superior in removing baseline wander, while preserving the ST segment. The approach compares favorably also in
ii
in data 23/04/2013.
Abstract
terms of computational complexity, which is linear in the size of the vector to detrend. This makes it suitable for real-time applications as well as for applications
on devices with reduced computing power, e.g., handheld devices.
All the techniques described for smoothing, rejection of power-line noise and,
in general, narrowband artifacts, either for single waves or entire ECGs, and for
baseline wander removal, share a common approach, although with different technicalities. This approach is based on the notion of quadratic variation reduction
and constitutes the common framework for ECG signal processing, which is the
object of this dissertation.
