Dario Rossi, Politecnico di Torino
WSN: THE TOSSIM SIMULATOR
6-8 june 2006
Dario Rossi
Politecnico di Torino
[email protected]
Wireless Sensor Network
Copyright – Tutti i diritti riservati
1
Copyright
• Questo insieme di trasparenze (detto nel seguito slides) è protetto dalle leggi sul copyright e dalle disposizioni dei
trattati internazionali. Il titolo ed i copyright relativi alle slides (ivi inclusi, ma non limitatamente, ogni immagine,
fotografia, animazione, video, audio, musica e testo) sono di proprietà degli autori indicati a pag. 1.
• Le slides possono essere riprodotte ed utilizzate liberamente dagli istituti di ricerca, scolastici ed universitari afferenti
al Ministero della Pubblica Istruzione e al Ministero dell’Università e Ricerca Scientifica e Tecnologica, per scopi
istituzionali, non a fine di lucro. In tal caso non è richiesta alcuna autorizzazione.
• Ogni altra utilizzazione o riproduzione (ivi incluse, ma non limitatamente, le riproduzioni su supporti magnetici, su
reti di calcolatori e stampate) in toto o in parte è vietata, se non esplicitamente autorizzata per iscritto, a priori, da
parte degli autori.
• L’informazione contenuta in queste slides è ritenuta essere accurata alla data della pubblicazione. Essa è fornita per
scopi meramente didattici e non per essere utilizzata in progetti di impianti, prodotti, reti, ecc. In ogni caso essa è
soggetta a cambiamenti senza preavviso. Gli autori non assumono alcuna responsabilità per il contenuto di queste
slides (ivi incluse, ma non limitatamente, la correttezza, completezza, applicabilità, aggiornamento
dell’informazione).
• In ogni caso non può essere dichiarata conformità all’informazione contenuta in queste slides.
• In ogni caso questa nota di copyright non deve mai essere rimossa e deve essere riportata anche in utilizzi parziali.
2
Outline
Motivations
Architecture Overview
• Compiler support
• Execution model
• Hardware/Radio models
• Communication services (TinyViz)
Evaluation
• Bridging, Fidelity, Scalability, Completeness
Extension
• PowerTOSSIM
3
Sensor Networks & Simulation
Sensor networks…
• Require large scale deployment (smart dusts)
• Located in physically inaccessible places
Apps are deployed…
• only once during network life time
• Little or no scope to re-deploy on errors
Early evaluation of the system…
• Is an integral part for development steering
• Check correctness of application behavior
• Sensors are pretty hard to debug
– Failure bug -> easier
– Operational but aberrant behavior -> harder
4
Debugging a Mote...
Used to require hardware modification...
...to the mote
(removal of a
resistor) ...
...to the board
(addition of jtag
connector)
5
Debugging a Mote
...still requires another hardware toy
...in TinyOS authors’ own words:
“Prepare to a slightly painful experience”
N. Ramanathan, K. Chang, R. Kapur, L. Girod, E. Kohler, and D. Estrin
Sympathy for the Sensor Network Debugger In Proc. of SenSys 2005.
6
Simulation Pros and Cons
Several advantages
• Study system in totally controlled environment
• Explore configuration difficult to construct
• Observe interaction difficult to live-capture
• Helps in design improvement
• Cost effective alternative
And disadvantages as well
• May not represent accurate real-world results
• Depends on several modeling assumptions
• Tradeoff details and accuracy for feasibility
7
Existing Tools?
Not very suitable for sensor networks
• Provides abstraction levels either
– too coarse -> packet level (ns-2, omnet++, Glomosim, …)
– too fine-grained -> instruction-level (Atemu, Proteus,…)
• Do not address the complex interactions
– Among motes (Application level)
– Within motes (Network stack)
– Motes and environment (Real world noise)
• Need to handle 2 parallel implementations
– One for the real motes, one for the simulator
Need for simulator tightly bound to TinyOS
8
Key Requirements
Scalability
• How many ?
Completeness
• How much ?
Fidelity
• How similar ?
Bridging
• How easy ?
9
Key Requirements
Scalability
• Largest real deployment: 850 nodes (20,000 secreted)
• Must handle these sizes and above
Completeness
• Cover as many interaction as possible
• Simulating complete application is required
Fidelity
• Capture network interaction at a fine grain
• Must be able to reveal unanticipated interactions
Bridging
• Bridge the gap between algorithm and implementation
• Often, algorithm is sound but implementation is not
10
TOSSIM Architecture
•Discrete-event simulator
•Utilizes TinyOS’s component based architecture
•Transparently integrated
within TinyOS
–providing a new hardware
resource abstraction layer
–TinyOS event-driven
execution maps well to a
discrete-even simulation
11
TOSSIM Architecture
12
TOSSIM Architecture
Architectual points
•Compiler Support
•Execution Model
•Hardware Emulation
•Radio Model
•Communication Service
13
Compiler Support
MOTE nesC
Component frame
MOTE C
Currently running mote
TOSSIM C
14
Execution Model
Simple event queue
• Substitute TinyOS scheduler
• Interrupts == simulator events
• Simulator events != TinyOS events
• Interrupts are NOT pre-emptive
Time unit
• Mote clock granularity (4 Mhz)
• Delta time (similar to VHDL)
–Events do not take any virtual time to execute
–Infinite delta time adds up to zero virtual time
15
Hardware Emulation
Hardware
• TinyOS abstract hardware as component
• TOSSIM emulates hardware components
–ADC, Clock, EEPROM, radio, potentiometer,...
Emulation
• Split-phase operations preserved
–Latency taken from real world sensor-boards
• External function provides readings
–Constant (changeable at run-time) or random
• Radio chip handled specially
–Channel state depends on Radio Model (error is NOT)
–Signal is 1 or 0 (interference is OR, worst case)
16
Radio Model
Directed graph of bit-error probabilities
• Pros
–Flexible, changeable at run-time
–Asymmetric links
• Cons
–Signal strength not considered
–Independent bit errors
• Simple models provided
x
ex,z
ez,x z
y
–Error free links (for debugging)
–Bit error extrapolated from measured packet loss rates
17
Communication Service
Exchange data over TCP/IP
• Sim -> App: debug msg, pkts as over UART
• App -> Sim: commands, inject pkts, turn
motes on/off
TinyViz GUI
• Vizualization/Actuation
• Real/Simulated network
• Customizable
18
Communication Service
Plug-ins
GUI
Event Bus
Communication
Drawing
SerialForwarder
Event/Msg
TOSSIM
19
Commands
Evaluation
Scalability
• How many ?
Completeness
• How much ?
Fidelity
• How similar ?
Bridging
• How easy ?
20
Evaluation: Scalability
21
Evaluation: Scalability
Surge
Sim Queue
Other
Radio
Base
For instance, 10 simulated seconds
pkt level = 25 seconds real time
bit level > 1 hour real time
22
Evaluation: Completeness
TOSSIM is complete enough
• But limited to ONE application at a time
TinyOS debugging
• Debug TinyOS radio stack
–Discovered & fixed problems that were
unnoticed during testbed deployment
–Possible thanks to the bit-level granularity
• Debug applications
–Discovered & debug the Surge application
–Surge requires complex interaction between
components
23
Surge Application: high loss rate
Send queue often
overflows... But why ?
24
Surge Application: bug fixes
1) Duplicate suppression
in send queue
2) Break all routing cycles
Send queue often
overflows... But why ?
25
Evaluation: Fidelity
Fidelity Effort
• Bit granularity
• Simulates ADC readings
• Simulates interrupts
Some Imperfections
• Does not model radio propagation
–bit-level error abstraction
• Interrupts are NOT pre-emptive
• Only RFM (MICA) and CC1000 (MICA2)
networking stacks
26
Evaluation: Fidelity
)
)
)
)
)
)
(
(
(
(
( Medium power (
1
2 ft
...
2
200 pkts
27
...
25
Evaluation: Bridging
TinyOS core integration
• Instrumented nesC compiler
• Transparently compiles application code
(make pc)
(make mica2)
–for TOSSIM
–for specific hardware
• Tested code can be deployed right away
TinyOS tools integration
• Available tools can cooperate with TOSSIM
–TinyViz, SerialForwarder
28
Extension: PowerTOSSIM
Goals
•Power profiling
•CPU profiling
•MICA2 radio
29
PowerTOSSIM: Benchmark
•Develop a hardware power model
•Isolate the power consumption of
different hardware devices
•Microbenchmarks
•CPU (different known power levels,
instruction count)
•Radio (different power levels)
•EEPROM (read/write)
•Sensing unit
30
PowerTOSSIM: Power Model
31
PowerTOSSIM: Architecture
•Add module to
track power state
•Minor modification
required to synth.
hw. components
•Decouple data
gathering from
processing (Python)
32
PowerTOSSIM: Implementation
33
PowerTOSSIM: Validation
Measured
CntToLedsAndRfm
•Cnt++
•putLeds(Cnt & 0x07)
•sendPkt(Cnt)
0
34
2
4
6
Simulated
Measured
35
36
Conclusion
TOSSIM
• Simulates TinyOS applications
• Can be useful during development phase
TOSSIM is
• Integrated into TinyOS
– The same code can be used for simulation and real test-beds
• Extensible
– Radio Stack, Power and CPU Profiling.
– Extension may be however tricky
• Scalable enough
– But possibly very slow
• Results are quite accurate
– But not authoritative
37
References
•.Levis, N. Lee, M. Welsh and D. Culler, TOSSIM: Accurate and
Scalable Simulation of Entire TinyOS Applications, In Proc. of
SenSys 2003.
V Shnayder, M Hempstead, B Chen, GW Allen, M Welsh,
Simulating the power consumption of large-scale sensor network
applications. In Proc. of SenSys 2004
