GTH
(Mil. Std. No.: MS90387-2)
PA24634A01
Rev. 05 3-2013
CABLE TIE INSTALLATION TOOL OPERATING INSTRUCTIONS
© Panduit Corp. 2013
FOR INSTALLING:
Pan-Ty, Dome-Top Barb Ty, Sta-Strap, Dura-Ty, Contour-Ty, and In-Line Cable Ties
of Standard, Heavy-Standard, Light-Heavy, and Heavy cross sections.
1
2
A
STD:
.19”
(4.8mm)
HVY-STD:
.25”
(6.3mm)
LHVY:
.30”
(7.6mm)
HVY:
.30 - .35”
(7.6 - 9mm)
B
TOOL MAINTENANCE: GTH
C
This tool requires no special operator
maintenance.
0-4
ENGLISH
A
REPLACEMENT KITS and
ACCESSORIES: (Sold Separately)
D: KGTHTL – Tension Locking Kit
E: KGTHBLD – Blade Replacement Kit
F: WH24287C02 – Blade Guard
WH25092A01 – Extended Blade Guard
Technical Support:
Tel: 888-506-5400, ext. 83255
4-6
E-mail: [email protected]
5-6
Technical Support: Panduit Europe
EMEA Service Center, Almelo, Netherlands
Tel: +31 546-580-452 • Fax: +31 546-580-441
EU Website: www.panduit.com/emea
E-mail: [email protected]
5-8
www.panduit.com
Page: 1 of 2
ESPAÑOL
ITALIANO
FRANÇAIS
DEUTSCH
© Panduit Corp. 2013
OPERATING INSTRUCTIONS
GTH
WARTUNG: GTH
Das Werkzeug bedarf keinerlei Wartung.
ERSATZTEILSATZ UND ZUBEHÖR: (Separater Verkauf)
D: Satz für Spannungssperre – KGTHTL
F: Klingenschutz – WH24287C02
E: Messersatz – KGTHBLD
Klingenschutz (Ausgedehnt)–WH25092A01
ENTRETIEN DE L’OUTIL: GTH
Cet outil ne requiert aucun entretien spécial de la part de l’opérateur.
KITS DE REMPLACEMENT ET ACCESSOIRES: (Vendu Séparemment)
D: Kit Raidisseur – KGTHTL
F: Protege lame – WH24287C02
E: Kit de Remplacement de Lame –
Protege lame (Prolongé) – WH25092A01
KGTHBLD
MANUTENZIONE DELL’ATTREZZO: GTH
Questo attrezzo non ha bisogno di una manutenzione speciale de parte dell’operatore.
KIT DI RICAMBIO E ACCESSORI: (Venduti Separatamente)
D: Kit di Blocco della Tensione – KGTHTL F: Protezione della Lama – WH24287C02
E: Kit per il Recambio della Lama –
Protezione della Lama (Esteso) –
KGTHBLD
WH25092A01
MANTENIMIENTO DE LA HERRAMIENTA: GTH
Esta herramienta no requiere mantenimiento especial por parte del operador.
ACCESSORIOS Y JUEGO DE REPUESTOS: (Se vende separado)
D: Juego de Fijación de la Tensión–KGTHTL F: Protector de la Cuchilla–WH24287C02
E: Juego de Cuchilla de Repuesto–KGTHBLD
Protector de la Cuchilla (Extendido) –
WH25092A01
Page: 2 of 2
